Schneider Electric LUB120 LUB120 kontrolna enota

Blagovna znamka Schneider Electric

(0 ocen)

69,99 EUR 77,99 EUR 10% popusta

Koda izdelka: 2913800
EAN: 3389110362794
Predvidena dobava:01.10.2026 - 02.10.2026

Opis

Motorni napajalniki TeSys U je prvi inteligentni motorni napajalnik, ki združuje nadzor, preklapljanje in zaščito v eni napravi. Kompakten, preprost in modularen se prilagaja vsem aplikacijam.

Besedilo je strojno prevedeno.

Varnost izdelkov (GPSR)

Proizvajalčeva koda: LUB120

EAN koda: 3389110362794

Registrirana blagovna znamka: Schneider Electric

Ime proizvajalca: Schneider Electric GmbH

Naslov proizvajalca: Gothaer Str. 29

Poštna številka proizvajalca: 40880

Kraj proizvajalca: Ratingen

Država proizvajalca: Germany

Telefon proizvajalca: +4921173743000

Elektronski kontakt proizvajalca: https://www.se.com/

Kontakt odgovorne osebe za varnost: [email protected]

Država odgovorne osebe za varnost: Nemčija

Dokumenti

Tehnični podatki 2913800 Schneider Electric LUB120 LUB120 kontrolna enota

Informacije 2913800 Schneider Electric LUB120 LUB120 kontrolna enota

Navodila za uporabo in varnost 2913800 Schneider Electric LUB120 LUB120 kontrolna enota

Tehnični podatki

Vrsta izdelka	kontrolna enota
Proizv. št. delov	LUB120
Vrsta	LUB120
Teža	0
Width	45
Height	154 mm
Depth	126 mm
With transformer	FALSE
Rated operation power at AC-3, 400 V	5.5 kW
Number of command positions	3
Number of auxiliary contacts as normally open contact	1
Number of auxiliary contacts as normally closed contact	1
Suitable for emergency stop	FALSE
Rated operation current Ie	12 A
Number of indicator lights	0
Supporting protocol for LON	FALSE
Supporting protocol for TCP/IP	FALSE
Supporting protocol for ASI	FALSE
Supporting protocol for PROFIBUS	FALSE
Supporting protocol for CAN	FALSE
Supporting protocol for INTERBUS	FALSE
Supporting protocol for Modbus	FALSE
Supporting protocol for Data-Highway	FALSE
Supporting protocol for DeviceNet	FALSE
Supporting protocol for SUCONET	FALSE
Supporting protocol for other bus systems	FALSE
External reset possible	FALSE
Suitable for rail mounting	TRUE
Degree of protection (IP)	IP20
Supporting protocol for SERCOS	FALSE
Supporting protocol for INTERBUS-Safety	FALSE
With short-circuit release	TRUE
With fuse	FALSE
Type of electrical connection of main circuit	Screw connection
Type of electrical connection for auxiliary- and control current circuit	Screw connection
Supporting protocol for AS-Interface Safety at Work	FALSE
Supporting protocol for DeviceNet Safety	FALSE
Supporting protocol for EtherNet/IP	FALSE
Supporting protocol for Foundation Fieldbus	FALSE
Supporting protocol for PROFINET CBA	FALSE
Supporting protocol for PROFINET IO	FALSE
Supporting protocol for PROFIsafe	FALSE
Supporting protocol for SafetyBUS p	FALSE
Voltage type for actuating	AC/DC
Type of motor starter	Direct online starter (DOL)
Rated operation power at AC-3, 230 V, 3-phase	3 kW
Rated power, 460 V, 60 Hz, 3-phase	5.5 kW
Rated power, 575 V, 60 Hz, 3-phase	5.5
Rated operation current at AC-3, 400 V	12 A
Ambient temperature, upper operating limit	70 °C
Rated conditional short-circuit current, type 2, 400 V	50000
Rated conditional short-circuit current, type 2, 230 V	50000
Rated conditional short-circuit current, type 1, 480 Y/277 V	10000
Rated conditional short-circuit current, type 1, 600 Y/347 V	4000
Coordination class according to IEC 60947-4-3	Class 2
UKCA	da
