Opis
SIMATIC HMI TP1500Comfort Pro, podporna ročica, Comfort Panel, upravljanje na dotik, 15 "širokozaslonski TFT zaslon 16 MIO barv, vmesnik PROFINET, vmesnik MPI / PROFIBUS-DP, konfiguracijski pomnilnik 24 MB, WEC 2013, nastavljiv iz WinCC Comfort V14 SP1 s HSP SIMATIC HMI TP1500Comfort Pro, podporna ročica, Comfort Panel, krmiljenje na dotik, 15-palčni širokozaslonski TFT zaslon 16 MIO barv, vmesnik PROFINET, vmesnik MPI / PROFIBUS-DP, konfiguracijski pomnilnik 24 MB, WEC 2013, nastavljiv iz WinCC Comfort V14 SP1 s HSP Pripravljen za podporno roko brez Razširitveni elementi SIMATIC HMI Comfort Panel TP1500 Comfort PRO
Besedilo je strojno prevedeno.
Varnost izdelkov (GPSR)
Proizvajalčeva koda: 6AV21240QC240AX0
EAN koda: 4047623408796
Registrirana blagovna znamka: Siemens
Ime proizvajalca: Siemens AG
Naslov proizvajalca: Siemenspromenade 2
Poštna številka proizvajalca: 91058
Kraj proizvajalca: Erlangen
Država proizvajalca: Germany
Telefon proizvajalca: +498938035491
Elektronski kontakt proizvajalca: https://www.siemens.com/
Kontakt odgovorne osebe za varnost: [email protected]
Država odgovorne osebe za varnost: Nemčija
Dokumenti
Tehnični podatki 1759312 Siemens 6AV2124-0QC24-0AX0 6AV21240QC240AX0 prikazovalnik za PLC-krmilnik
Tehnični podatki 1759312 Siemens 6AV2124-0QC24-0AX0 6AV21240QC240AX0 prikazovalnik za PLC-krmilnik
Tehnični podatki 1759312 Siemens 6AV2124-0QC24-0AX0 6AV21240QC240AX0 prikazovalnik za PLC-krmilnik
Tehnični podatki 1759312 Siemens 6AV2124-0QC24-0AX0 6AV21240QC240AX0 prikazovalnik za PLC-krmilnik
Tehnični podatki 1759312 Siemens 6AV2124-0QC24-0AX0 6AV21240QC240AX0 prikazovalnik za PLC-krmilnik
Tehnični podatki 1759312 Siemens 6AV2124-0QC24-0AX0 6AV21240QC240AX0 prikazovalnik za PLC-krmilnik
Tehnični podatki
| Vrsta izdelka |
prikazovalnik za PLC-krmilnik |
|---|---|
| Vrsta |
6AV2124-0QC24-0AX0 |
| Proizv. št. delov |
6AV21240QC240AX0 |
| Širina |
396 mm |
| Izvedba |
Pripravljen za podporno roko brez podaljškov |
| Poraba toka |
1500 mA |
| Vsebina |
1 kos |
| Prikaz |
da |
| Serija |
Siemens-HMI |
| Zaslon (palec) |
15 palec |
| Built-in depth |
101 mm |
| Suitable for safety functions |
FALSE |
| Screen diagonal |
15.6 mm |
| Voltage type (supply voltage) |
DC |
| Supporting protocol for LON |
FALSE |
| Number of HW-interfaces industrial Ethernet |
2 |
| Number of HW-interfaces RS-232 |
0 |
| Number of HW-interfaces RS-422 |
0 |
| Number of HW-interfaces RS-485 |
1 |
| Number of HW-interfaces serial TTY |
0 |
| Number of HW-interfaces USB |
2 |
| Number of HW-interfaces parallel |
0 |
| Number of HW-interfaces other |
0 |
| Supporting protocol for TCP/IP |
TRUE |
| Supporting protocol for ASI |
FALSE |
| Supporting protocol for PROFIBUS |
TRUE |
| Supporting protocol for CAN |
FALSE |
| Supporting protocol for INTERBUS |
FALSE |
| Supporting protocol for KNX |
FALSE |
| Supporting protocol for Modbus |
TRUE |
| Supporting protocol for Data-Highway |
FALSE |
| Supporting protocol for DeviceNet |
FALSE |
| Supporting protocol for SUCONET |
FALSE |
| Supporting protocol for other bus systems |
TRUE |
| Colour display |
TRUE |
| Number of colours of the display |
16777216 |
| Number of pixels, horizontal |
1366 |
| Number of pixels, vertical |
768 |
| Number of function buttons, programmable |
0 |
| With numeric keyboard |
TRUE |
| With alpha numeric keyboard |
TRUE |
| Usable project memory/user memory |
24000 kB |
| With message indication |
TRUE |
| With message system (incl. buffer and confirmation) |
TRUE |
| Process value representation (output) possible |
TRUE |
| Process default value (input) possible |
TRUE |
| With recipes |
TRUE |
| Number of password levels |
50 |
| With printer output |
TRUE |
| Number of online languages |
32 |
| Additional software components, loadable |
TRUE |
| Degree of protection (IP), front side |
IP65 |
| With SW interfaces |
FALSE |
| Width of the front |
396 mm |
| Height of the front |
225.5 mm |
| Suitable for rail mounting |
FALSE |
| Supporting protocol for SERCOS |
FALSE |
| Supporting protocol for INTERBUS-Safety |
FALSE |
| Number of interfaces PROFINET |
2 |
| Number of HW-interfaces wireless |
0 |
| Wall mounting/direct mounting |
FALSE |
| Radio standard Bluetooth |
FALSE |
| Radio standard WLAN 802.11 |
FALSE |
| IO link master |
FALSE |
| Supporting protocol for AS-Interface Safety at Work |
FALSE |
| Supporting protocol for DeviceNet Safety |
FALSE |
| Supporting protocol for EtherNet/IP |
TRUE |
| Supporting protocol for Foundation Fieldbus |
FALSE |
| Supporting protocol for PROFINET CBA |
FALSE |
| Supporting protocol for PROFINET IO |
TRUE |
| Supporting protocol for PROFIsafe |
FALSE |
| Supporting protocol for SafetyBUS p |
FALSE |
| Type of display |
TFT |
| Number of grey-scales/blue-scales of display |
0 |
| Radio standard GPRS |
FALSE |
| Radio standard GSM |
FALSE |
| Mobile communications standard 3G (UMTS) |
FALSE |
| Number of buttons with LED |
0 |
| Number of system buttons |
0 |
| Touch technology |
Capacitive multitouch |
| UKCA |
da |
